Observing Privilege Escalation in Kubernetes (EKS CloudWatch Observability Add-on)

What it is

The CloudWatch Observability Add-on's cloudwatch-agent service account (shared by the cloudwatch-agent and fluent-bit DaemonSets, present on every node) held a cluster-scoped update permission on ConfigMaps in add-on versions through v4.10.1-eksbuild.1 and earlier, tested by Reversec against Kubernetes v1.35.

How it works

flowchart TD
    A[Attacker deploys privileged pod with hostPath mount] --> B[Reads /var/lib/kubelet/pods on host]
    B --> C[Extracts cloudwatch-agent SA token from another pod's volume]
    C --> D[kubectl edit fails: no 'patch' perm]
    D --> E[kubectl edit still writes local YAML copy]
    E --> F[kubectl replace succeeds: 'update' perm is sufficient]
    F --> G[aws-auth ConfigMap rewritten: user added to system:masters]
    G --> H[Cluster-admin]

kubectl edit fails because it uses patch, but it still writes the proposed manifest locally; kubectl replace -f against that file uses update, which the service account does have — so the missing patch permission is not a real barrier. A second, separate escalation path exists via the get permission on nodes/proxy, which (per a blog post by Graham Helton, referenced but not detailed here) allows code execution on pods via the kubelet API; this is unrelated to the ConfigMap issue and was not fixed by AWS's patch.

Preconditions / Affected

• EKS cluster using "EKS API and ConfigMap" authentication mode (ConfigMap-mode clusters only — pure EKS API/access-entry mode is not affected since access entries override the ConfigMap).
• CloudWatch Observability Add-on in default configuration, version ≤ v5.2.x (confirmed vulnerable at v4.10.1-eksbuild.1).
• Attacker needs node-level access, e.g. via a privileged pod with hostPath access to /var/lib/kubelet/pods to read other pods' service-account tokens.

What to do

• Upgrade the add-on to v5.3.0-eksbuild.1 or later: this version introduces a new namespaced cloudwatch-agent-role in the amazon-cloudwatch namespace holding the ConfigMap update permission, and removes that permission from the cluster-wide role — closing the aws-auth escalation path specifically.
• This upgrade does not touch the nodes/proxy permission; that escalation path remains open on all current versions and is tracked separately against Kubernetes 1.36's "fine-grained Kubelet authorization," which went GA in that release per the author's post-talk update. EKS was still capped at Kubernetes v1.35 as of 3 June 2026, so no EKS-side fix was available at time of writing.
• Where migration to EKS API/access-entry auth isn't possible, mitigate via Pod Security Standards restricting privileged/hostPath pods, and audit third-party add-on service-account permissions directly (the author recommends IceKube for mapping escalation paths).

Caveats

Reversec could not confirm whether a fully namespaced role (no cluster role at all) is viable for the agent — EKS's managed add-on update process repeatedly auto-restored the cluster role during testing, so the namespacing fix's completeness is AWS's implementation, not independently verified by the author. The nodes/proxy mitigation (restricting kubelet port traffic) is noted as unverified and potentially disruptive.
